6 Rugby 870/880 Menu
6.1 Access and Navigation
Description The Rugby 870/880 has several menu options that allow you to optimise the perfor-
mance of the Rugby for an individual application.
To access the menu of the Rugby 870/880, press the Left and Right Arrow Buttons
simultaneously while the main screen is displayed.
Navigation within the Menu:
In the bottom right-hand corner of the menu screen, there are
displayed User Direction buttons to indicate the navigation
within the Rugby menu.
Press the Up and Down Arrow Buttons to move the cursor and highlight an icon or an
option.
A highlighted icon is surrounded by a box
.
A highlighted option is shaded in black.
Press the Grade Button to select a highlighted icon or to enable/disable a highlighted
option.
•
If you select an icon, a screen with the options for the selected icon is displayed.
•
If you select the menu icon (MENU 1, MENU 2, MENU 3), the next menu set is
displayed.
•
If you select the EXIT icon, the system returns to the main screen.
007606_001
007607_001
007608_001
To Next Page
