Rugby 870/880, Technical Data
66
14 Technical Data
14.1 Conformity to National Regulations
Conformity to
national regulations
Frequency band 2400 - 2483.5 MHz
Output power < 100 mW (e. i. r. p.)
Antenna
14.2 General Technical Data of the Laser
Operating range Operating range (diameter):
Self-levelling accu-
racy
Self-levelling accuracy is defined at 25°C (77°F)
Self-levelling range
Head speed
Laser dimensions
• FCC Part 15 (applicable in US)
• Hereby, Leica Geosystems AG, declares that the product Rugby 870/880 is in
compliance with the essential requirements and other relevant provisions of Direc-
tive 1999/5/EC and other applicable European Directives. The declaration of
conformity may be consulted at http://www.leica-geosystems.com/ce.
Class 1 equipment according European Directive 1999/5/EC (R&TTE) can be
placed on the market and be put into service without restrictions in any EU
Member state.
• The conformity for countries with other national regulations not covered by the FCC
part 15 or European directive 1999/5/EC has to be approved prior to use and oper-
ation.
• Japanese Radio Law and Japanese Telecommunications Business Law Compliance.
– This device is granted pursuant to the Japanese Radio Law and the Japanese
Telecommunications Business Law.
– This device should not be modified (otherwise the granted designation number
will become invalid).
Rugby 870/880 Chip antenna
Rod Eye 180, Digital RF Receiver Chip antenna
Rugby 870/880: 1100 m/3600 ft
Self-levelling accuracy: ±1.5 mm at 30 m (±1/16" at 100 ft)
Self-levelling range: ±6°
Head speed: 5, 10 rps
007848_001
237 mm (9.33")
240.5 mm (9.47") 196 mm (7.72")
