2.Removetheservercover.See“Removingtheservercover”onpage85.
3.Laytheserveronitssideforeasieroperation.
4.LocatethePCI-Eslot3onthesystemboard.See“Systemboardcomponents”onpage42.
5.Removeanypartsordisconnectanycablesthatmightimpedeyouroperation.
6.Touchthestatic-protectivepackagethatcontainstheRAIDcardtoanyunpaintedsurfaceonthe
outsideoftheserver.Then,taketheRAIDcardoutofthepackage.
Note:CarefullyhandletheRAIDcardbyitsedges.
7.TheRAIDcardisakindofPCIcard.See“InstallingaPCIcard”onpage93andfollowthoseinstructions
toinstalltheRAIDcard.
8.Connectcablesdependingonyourspecicserverconguration.See“Connectingcables”onpage38.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage162.Then,congure
RAIDforyourserver.See“ConguringRAID”onpage71.
RemovingtheRAIDcard
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage83.
ThistopicprovidesinstructionsonhowtoremovetheRAIDcard.
Attention:MakesurethatyoubackupyourdatabeforeremovingtheRAIDcardbecauseyoumightneedto
recongureRAIDandreinstalltheoperatingsystemafterremovingtheRAIDcard.IfyouremovetheRAID
card,youwilllosetheadvancedSATA/SAShardwareRAIDfunctions.Also,aspecicRAIDcardisrequired
forservermodelswithmorethanfourharddiskdrivesormodelsthatuseSASharddiskdrives.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Note:UseanydocumentationthatcomeswiththeRAIDcardandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ToremovetheRAIDcard,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage85.
3.Laytheserveronitssideforeasieroperation.
4.LocatetheRAIDcard,whichisinstalledinthePCI-Eslot3onthesystemboard.See“Systemboard
components”onpage42.
5.Removeanypartsordisconnectanycablesthatmightimpedeyouroperation.
6.DisconnectallcablesfromtheRAIDcardandanyotherrelatedparts.
Note:IfyouwanttoinstallanewRAIDcardafterremovingtheoldone,notedownthecable
connectionsbeforedisconnectingthecables.
7.TheRAIDcardisakindofPCIcard.See“RemovingaPCIcard”onpage95andfollowthose
instructionstoremovetheRAIDcard.
Note:CarefullyhandletheRAIDcardbyitsedges.
Chapter6.Installing,removing,orreplacinghardware99
