Note:TheDITmoduleisonlyavailableinsomemodels.
ThefollowingillustrationshowsthelocationoftheDITmoduleandthediagnosticLEDsontheDITpanelin
thefrontoftheserver.Dependingonthemodel,yourservermightlookslightlydifferentfromthefollowing
illustration.
Figure5.DITpanel
1MicroprocessorerrorLED4AmbienttemperatureoverlimitLED
2MemorymoduleerrorLED
5PowersupplyerrorLED(onlyavailableonmodelswith
redundantpowersupplymodules)
3FanerrorLED
1235ErrorLEDs
WhenoneoftheseerrorLEDsislit(orange),itindicatesthattheassociatedcomponenthasfailed.
4AmbienttemperatureoverlimitLED
WhenthisLEDislit(orange),itindicatesthattheambienttemperatureisover38°C(100.4°F).
Rearviewoftheserver
Thistopicprovidesinformationtohelpyoulocatetheconnectorsandcomponentsontherearofyourserver.
Chapter3.Productoverview19
