SystemboardLEDs
ThistopichelpsyoulocatetheLEDsonthesystemboard.
ThefollowingillustrationshowstheBMCstatusLED,systemboardhardwarefaultLED,andthePOSTcode
diagnosticLEDsonthesystemboard.
Figure30.SystemboardLEDs
1SystemboardhardwarefaultLED6POSTcodediagnosticLED#1
2BMCstatusLED7POSTcodediagnosticLED#6
3POSTcodediagnosticLED#48POSTcodediagnosticLED#2
4POSTcodediagnosticLED#0-LeastSignicant
Bit(LSB)
9POSTcodediagnosticLED#7-MostSignicantBit(MSB)
5POSTcodediagnosticLED#510POSTcodediagnosticLED#3
1SystemboardhardwarefaultLED
WhenthisLEDislit,itindicatesthatthesystemboardhardwarehasfailed.
50ThinkServerUserGuide
