3.Notetheorientationofthehot-swapredundantpowersupplymoduleandthenslidethenewhot-swap

redundantpowersupplymoduleintothechassisuntilitsnapsintoposition.

Note:Ifyourservercomeswithonehot-swapredundantpowersupplymoduleinstalledinthe

redundantpowersupplymodulebay1(thebaynumberismarkedontherearofthechassis)andyou

areinstallingasecondaryhot-swapredundantpowersupplymoduletoprovideredundantpower,you

needtoremovetheshieldthatprotectsthebay2rst.Savetheshieldforfutureuse.

Figure81.Installingahot-swapredundantpowersupplymodule

4.Ifyouareinstructedtoreturntheoldhot-swapredundantpowersupplymodule,followallpackaging

instructionsanduseanypackagingmaterialsthataresuppliedtoyouforshipping.

5.Toworkwithanotherpieceofhardware,gototheappropriatesection.

Replacingthepowerdistributionboardandcageassembly

Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”

onpageiii

and“Guidelines”onpage83.

Thistopicprovidesinstructionsonhowtoreplacethepowerdistributionboardandcageassembly.

Thistopicappliesonlytoservermodelsthatcomewithhot-swapredundantpowersupplymodules.

CAUTION:

Hazardousmovingparts.Keepngersandotherbodypartsaway.

Chapter6.Installing,removing,orreplacinghardware143
