Lexmark MS810 User Manual

4 Push the memory card straight into the connector, and then push the card toward the controller board wall until
it clicks into place.
5 Reattach the controller board shield, and then the controller board access cover.
Installing an Internal Solutions Port
The controller board supports one optional Lexmark Internal Solutions Port (ISP).
Note: This task requires a flathead screwdriver.
CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware or
memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord
from the electrical outlet before continuing. If you have any other devices attached to the printer, then turn
them off as well, and unplug any cables going into the printer.
Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity.
Touch something metal on the printer first before touching any controller board electronic components or
connectors.
1 Access the controller board.
For more information, see “Accessing the controller board” on page 14.
2 If an optional printer hard disk is installed, then remove the printer hard disk first.
For more information, see “Removing a printer hard disk” on page 29.
Additional printer setup 18

Lexmark MS810 Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 55 ppm
Print Resolution	1200 x 1200 dpi
Monthly Duty Cycle	Up to 300, 000 pages
Processor Speed	800 MHz
Standard Memory	512 MB
Maximum Memory	2560 MB
Connectivity	USB, Ethernet
Duplex Printing	Standard
Media Types Supported	Card Stock, Envelopes, Labels, Plain Paper, Transparencies
Maximum Paper Size	Legal
Operating System Compatibility	Windows, Mac, Linux
Input Capacity	650 pages (Standard)
Maximum Paper Input	4400 pages
