If you use a PBX or ISDN converter or terminal adapter, then follow these steps to connect the equipment:
1 Connect one end of the telephone cable that came with the printer to the LINE port on the back of the printer.
2 Connect the other end of the telephone cable to the port designated for fax and telephone use.
Notes:
• Make sure the terminal adapter is set to the correct switch type for your region.
• Depending on the ISDN port assignment, you may have to connect to a specific port.
• When using a PBX, make sure the call waiting tone is off.
• When using a PBX system, dial the outside line prefix before dialing the fax number.
• For more information on using the fax with a PBX system, see the documentation that came with your PBX
system.
Connecting to a Distinctive Ring Service
There is a plug installed in the EXT port of the printer. This plug is necessary for the proper functioning of the
printer.
Note: Do not remove the plug. If you remove it, other telecommunications devices in your home (such as telephones
or answering machines) may not work.
A distinctive ring service may be available from your telephone service provider. This service allows you to have
multiple phone numbers on one telephone line with each phone number having a different ring pattern. This may
be useful for distinguishing between fax and voice calls. If you subscribe to a distinctive ring service, follow these
steps to connect the equipment:
1 Connect one end of the telephone cable that came with the printer to bottom LINE jack on the back of the
printer.
2 Connect the other end of the telephone cable to an active analog telephone wall jack.
Faxing
78
