D9U001MC0-0101_1612

1.9 Denitions

Basic Bed Conguration the pricelist model conguration, not including a mattress

Bed Weight The value depends on the product conguration, accessories or customer

adjustments.

Clearance of Undercarriage the height from the oor to the lowest point of the undercarriage between

the castors, for the manipulation of accessories under a braked bed in the

standard position

Duty Cycle cycle of operation of the motor: time of activity/time of rest

Ergoframe Ergoframe is the kinematic system of Mattress support platform Adjustment

whose effect is the elimination of pressure on the patient´s abdomen and pel-

vic area and frictional forces on the patient‘s back and legs.

Maximum Patient Weight Maximum Patient Weight depends on the application environment according

to IEC 60601-2-52. For application environment 1 (intensive/critical care) and

2 (acute care) reduce Safe working Load by 65 kg. For application environ-

ment 3 (long-term care) and 5 (ambulatory care) reduce Safe working Load

by 35 kg.

Safe Working Load the highest allowable load on the bed (patient, mattress, accessories and the

load supported by those accessories)

Siderail Height the height of the upper crossbar or the edges of the siderails (not the highest

point of the siderail controls) from the patient surface

Standard Bed Position ■ The height of the patient surface with regard to the oor is 400 mm

■ The mattress support platform, including the individual parts, has to be in a

horizontal (level - 0°) position.

■ The siderails are always locked in the upper position.

■ The basic position of the integrated extension.

Adult Patient having a physical size equal to or more than 146 cm, a mass equal

to or more than 40 kg and a body mass index (BMI) equal to or more than 17

(according to IEC 60601-2-52).
