Linksys LAPN600 User Manual

17
SSL Certificate Screen
This screen can be used to manage SSL certificate used by HTTPS.
Figure 13: SSL Certificate Screen
Data - SSL Certificate Screen
Export/Restore to/from Local PC
Export SSL
Certificate
Click to export the SSL certificate.
Install Certificate
Browse to choose the certificate file. Click Install Certificate
button.
Export to TFTP Server
Destination File
Enter the name of the destination file.
TFTP Server
Enter the IP address for the TFTP server. Only support IPv4
address here.
Export
Click to export the SSL certificate to the TFTP server.

Linksys LAPN600 Specifications

General

Color	white
Wi-Fi Speed	600 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.1 pounds
