Linksys LAPN600 User Manual

40
Connection Control
Exclude or allow only listed client stations to authenticate with the access point.
Figure 27: Connection Control Screen
Data - Connection Control Screen
SSID
Select the desired SSID from the list.
Connection Type
Select the option from the drop-down list as desired.
• Local: Choose either Allow only following MAC addresses to
connect to wireless network or Prevent following MAC addresses
from connection to wireless network. You can enter up to 20
MAC addresses of wireless stations or choose the MAC
address.
• RADIUS
• Primary/Backup RADIUS Server - Enter the IP address of the
RADIUS Server.
• Primary/Backup RADIUS Server Port – Enter the Port
number of the RADIUS Server.
• Primary/Backup Shared Secret - This is shared between the
wireless access point and the RADIUS Server while
authenticating the device attempting to connect.
• Disabled

Linksys LAPN600 Specifications

General

Color	white
Wi-Fi Speed	600 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.1 pounds
