Linksys LAPN600 User Manual

19
Network Setup Screen
Use this screen to configure basic device settings, VLAN settings and settings for the LAN
interface, including static or dynamic IPv4/IPv6 address assignment.
Figure 14: Network Setup Screen
Data - Network Setup Screen
TCP/IP
Host Name
Assign a host name to this access point. Host name consists of 1 to 15
characters. Valid characters include A-Z, a-z, 0-9 and -. Character
cannot be first and last character of hostname and hostname cannot be
composed of all digits.
VLAN
Enables or disables VLAN function.
Untagged VLAN
Enables or disables VLAN tagging. If enabled (default), traffic from
the LAN port is untagged when the following conditions are met: 1)
VLAN ID is equal to Untagged VLAN ID and 2) untagged traffic can
be accepted by LAN port. If disabled, traffic from the LAN port is
always tagged and only tagged traffic can be accepted from LAN port.
By default all traffic on the access point uses VLAN 1, the default
untagged VLAN. All traffic will be untagged until you disable the
untagged VLAN, change the untagged traffic VLAN ID, or change the
VLAN ID for a SSID.

Linksys LAPN600 Specifications

General

Color	white
Wi-Fi Speed	600 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.1 pounds
