Linksys LAPN600 User Manual

51
LAN Status
LAN Status displays settings, and status of LAN interface.
Figure 33: LAN Status Screen
Data - LAN Status
VLAN
VLAN
Enabled or disabled (default).
Untagged VLAN
Enabled (default) or disabled.
When enabled, and if its VLAN ID is equal to Untagged VLAN
ID, all traffic is untagged when sent from LAN ports. Untagged
traffic can be accepted by LAN ports. If disabled, traffic is always
tagged when sent from LAN port and only tagged traffic can be
accept from LAN port.
By default all traffic on the access point uses VLAN 1, the default
untagged VLAN. This means that all traffic is untagged until you
disable the untagged VLAN, change the untagged traffic VLAN
ID, or change the VLAN ID for a SSID.
Untagged VLAN ID
Displays the untagged VLAN ID. Traffic on the VLAN that you
specify in this field is not be tagged with a VLAN ID when for-
warded to the network. VLAN 1 is the default ID for untagged
VLAN and management VLAN.

Linksys LAPN600 Specifications

General

Color	white
Wi-Fi Speed	600 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.1 pounds
