Linksys LAPN600 User Manual

41
Rate Limit
Limit downstream and upstream rate of SSIDs.
Figure 28: Rate Limit Screen
Data - Rate Limit Screen
Wireless Radio
Select the desired radio from the list.
Radio 1 is for 2.4 GHz, and Radio 2 is for 5 GHz.
Rate Limit
SSID
The index of SSID.
SSID Name
The name of the SSID.
Upstream Rate
Enter a maximum upstream for the SSID. The range is from 0 to 200
Mbps; 0 means no limitation.
Downstream
Rate
Enter a maximum downstream for the SSID. The range is from 0 to
200 Mbps; 0 means no limitation.

Linksys LAPN600 Specifications

General

Color	white
Wi-Fi Speed	600 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.1 pounds
