Linksys LAPN600 User Manual

65
Packet Capture
Packet Capture is used to capture and store 802.3 packets received and transmitted by the
access point based on one specified network interface. Network interface can be radio, SSID or
LAN.
Figure 43: Packet Size Screen
Data - Packet Size Screen
Network Interface
Select the desired network interface from the drop-down list.
The interface can be Radio, SSID or Ethernet.
Start Capture
Click it to start the capture. You will be asked to specify a
local file to store the packets.
Stop Capture
Click it to stop the capture.

Linksys LAPN600 Specifications

General

Color	white
Wi-Fi Speed	600 gigabits per second
Frequency Band	2.4 ghz
QoS Traffic Prioritization	no
Wireless Standard	n
Data Encryption	yes
Encryption Type	other, wep, wpa, wpa2
Security Features	rogue ap detection; ssid to vlan mapping; 802.1x supplicant
Ports	rj-45
Bluetooth	no

Weight and Dimensions

Height	1.72 inches
Width	9.33 inches
Net Weight	1.1 pounds
