16
Chapter 4: Using the Console Interface for Configuration
Configuring the Switch through the Console Interface
16- or 24-Port 10/100/1000 Gigabit Switch with WebView
File Management
The File Management screen allows you to upload or download files, such as the startup configuration, boot, or
image file, using a TFTP server.
Select Edit to change the settings. When your changes are complete, press the Esc key to return to the Action
menu, and select Execute to upload or download the designated file. After you download a file to the Switch, it
may need to be rebooted.
Restore System Default Settings
To restore the Switch back to the factory default settings, select Restore System Default Settings and press the
Enter key. You will be asked if you want to continue. Press the y key to restore the Switch’s default settings, or
press the n key to cancel.
Reboot System
Select Reboot System and press the Enter key if you want to restart the Switch. You will be asked if you want to
continue. Press the y key to reboot the Switch, or press the n key to cancel. After the Switch has rebooted, the
Switch Main Menu screen will appear.
Back to main menu
Select Back to main menu and press the Enter key if you want to return to the Switch Main Menu screen.
Figure 4-21: File Management
Figure 4-22: System Configuration Menu
Figure 4-20: TraceRoute Test Results
