50
Chapter 5: Using the Web-based Utility for Configuration
Maintenance Tab - File Upload
16- or 24-Port 10/100/1000 Gigabit Switch with WebView
Firmware Download
TFTP Server IP Address. Enter the IP address of the TFTP server.
Source File Name. Enter the name of the firmware file you want to download.
Destination File Name. Specify the file type, Software Image or Boot Code.
Configuration Download
TFTP Server IP Address. Enter the IP address of the TFTP server.
Source File Name. Enter the name of the configuration file you want to download.
Destination File Name. Specify the file type, Running Configuration or Startup Configuration. The Running
Configuration file holds all startup file commands and commands entered during the current session. The Startup
Configuration file holds the startup file commands needed by the Switch to power on or be rebooted.
Click the Submit button to begin the download of the firmware or configuration file.
Maintenance Tab - File Upload
The File Upload screen lets you upload firmware or a configuration file to a TFTP server. You cannot upload both
at the same time.
Firmware Upload. If you want to upload firmware, click this radio button. If this is selected, then the
Configuration Upload fields will not be available.
Configuration Upload. If you want to upload a configuration file, click this radio button. If this is selected, then
the Firmware Upload fields will not be available.
Software Image Upload
TFTP Server IP Address. Enter the IP address of the TFTP server.
Destination File Name. Enter the software image file path to which the file will be uploaded.
NOTE: You can perform only one type of upload at a time.
Figure 5-61: Maintenance - File Upload
Figure 5-60: File Download - Configuration Download
