40
Chapter 5: Using the Web-based Utility for Configuration
Statistics Tab - Etherlike Statistics
16- or 24-Port 10/100/1000 Gigabit Switch with WebView
Statistics Tab - Etherlike Statistics
The Etherlike Statistics screen displays interface statistics.
Interface. Select the appropriate interface, Port, LAG, or VLAN. Then select the appropriate number from the
drop-down menu.
Refresh Rate. Select how often you want the interface statistics refreshed.
Frame Check Sequence (FCS) Errors. Displayed here is the number of FCS errors received on the selected
interface.
Single Collision Frames. Displayed here is the number of single collision frames received on the selected
interface.
Late Collisions. Displayed here is the number of late collision frames received on the selected interface.
Excessive Collisions. Displayed here is the number of excessive collisions received on the selected interface.
Internal MAC Transmit Errors. Displayed here is the number of internal MAC transmit errors on the selected
interface.
Oversize Packets. Displayed here is the number of oversized packet errors on the selected interface.
Internal MAC Receive Errors. Displayed here is the number of internal MAC received errors on the selected
interface.
Received Pause Frames. Displayed here is the number of received paused frames on the selected interface.
Transmitted Pause Frames. Displayed here is the number of paused frames transmitted from the selected
interface.
Click the Clear All Counters button to reset all statistics to zero.
Figure 5-43: Statistics - Etherlike Statistics
