46
Chapter 5: Using the Web-based Utility for Configuration
Statistics Tab - RMON Events Log
16- or 24-Port 10/100/1000 Gigabit Switch with WebView
Description. This is the description of the event.
Type. This is the event type, Log, Trap, Log and Trap, or None. Log indicates that the event is a log entry. Trap
indicates that the event is a trap. An event can be both a log entry and a trap. None indicates that no event has
occurred.
Time. This is the time at which the event occurred.
Owner. This is the user that defined the event.
To delete an entry, click its X icon.
To add an entry, click the paper and pencil icon. On the new screen that appears, you can configure its settings.
Event Entry. This is the number of the event.
Community. Enter the name of the event’s community.
Description. Describe the event in this field.
Type. Select the event type, Log, Trap, Log and Trap, or None. Log indicates that the event is a log entry. Trap
indicates that the event is a trap. An event can be both a log entry and a trap. None indicates that no event has
occurred.
Owner. Enter the name of the user defining this event.
Click the Submit button to save your changes.
Statistics Tab - RMON Events Log
The RMON Events Log screen displays a list of RMON events.
Event. This is the number of the RMON Event Log entry.
Log No. This is the log number.
Log Time. This is the time when the log entry was entered.
Description. This is the description of the log entry.
Figure 5-51: RMON Events Control - Add Entry
Figure 5-52: Statistics - RMON Events Log
