Mahindra 60 Series User Manual

51
60 Series 2WD/4WD, Model - 8560
Wheel Tread Adjustment
Adjustment of Front Wheel Tread - 4WD
Setting of various offset combinations can result in
adjustment of the Front wheel tread.
The Wheel tread obtained with Front Tire size 9.5L x 24 is
as follows :
Offset
ABCDE
mm/ mm/ mm/ mm/ mm/
inch inch inch inch inch
Front Wheel
1644 1679 1791 1831 1943
64.72 66.10 70.51 72.08 76.5
Adjustment of Rear Wheel Tread
The rear wheel tread obtained with Rear Tire size 16.9 x 28
is as follows :
An arrow is marked on the sidewall of the tire,
which must always point in the direction of
forward rotation to obtain maximum traction.
Offset
ABCDE
mm/ mm/ mm/ mm/ mm/
inch inch inch inch inch
Rear Wheel
1509 1600 1712 1803 1916
59.4 63 67.4 71 75.4
