83
60 Series 2WD/4WD, Model - 8560
Special Bolt Torques N.m / Lbs. ft.
N.m Lbs. ft.
Bolt for cover cylinder head 25 ± 3 16 - 20
Bolt cylinder head* 90±5 + 60
0
+ 60
0
66-70 + 60
0
+ 60
0
Bolt crankshaft gear 65 ± 5 44 - 52
Bolt crankshaft main bearing cap 168 ± 8 118 - 130
Bolt connecting rod 65 ± 5 44 - 52
Bolt flywheel mounting 168 ± 8 118 - 130
Bolt for swinging drawbar mounting 275 ± 25 185 - 221
Nut carrier rear axle 112 ± 12 74 - 91
Drain plug for engine oil pan 85 ± 5 59 - 66
Bolt fender mounting M8 21 - 24 16 - 18
Bolt fender mounting M12 65 ± 5 48 - 52
Nut for front axle support 200 - 225 148 - 167
Nut for jerrycan weight 340 - 400 240 - 262
Nut steering wheel 50 - 55 37 - 41
Nut rear wheel 350 - 400 260 - 295
Nut rear wheel weight 250 - 275 184 - 202
Nut rear wheel rim / disc 200 - 280 148 - 206
Nut front wheel 290 - 300 213 - 221
Nut front wheel rim / disc 200 - 280 148 - 206
Nut lock spiral pinion bevel shaft 180 - 200 132 - 162
Drop box drain plug 40 - 47 29 - 33
Transmission drain plugs 70 - 77 51 - 56
* First torque all bolts to 90±5 N.m (66-70 Lbs.ft) then rotate it by 60
0
and again rotate it by 60
0
as per
torquing sequence.
Special Bolt Torques
