84
60 Series 2WD/4WD, Model - 8560
Specifications
MAHINDRA – 8560 2WD
ENGINE
Four Stroke, Turbo Charged, Intercooled, Direct Injection,
Water Cooled Diesel Engine
Model : NE 479 TCI
No. of Cylinders : 4
Displacement : 203.2 cubic inch.
Bore : 3.78 in.
Stroke : 4.53 in.
Compression Ratio : 17.2:1
Max. Engine Hp* : 83 max. as per DIN-70020
(Manufacturing Rating)
Rated Speed : 2300 rpm
High Idle r.p.m. : 2500 ± 50
Low Idle r.p.m. : 850 ± 50
Fuel Injection Pump : Rotary FIP with KSB
Unit MICO (BOSCH)
Cylinder Sleeve : Wet-Replaceable
Air Cleaner : Dry type with safety
cartridge & dust
unloader valve
Exhaust Muffler : Vertical
Firing Order : 1 - 3 - 4 - 2
Accelerator : Hand & foot accelerator
Injector Opening Pressure : 3625 - 3742 PSI
Electrical Starting and Lighting
Battery Capacity : 12 volt
Starter : Solenoid engaged.
Key start with interlock
safety neutral switch.
Alternator : 12 volt, 55 amp
Instrument Cluster :
Gauges : Electronic RPM cum
Hour Meter, Coolant Temp.
Gauge, Fuel Level Gauge
Indicator : Annunciator
Window (Bulb Indicators) -
High Temp., Fault, Healthy,
Low Oil Pressure, Service
Trailer.
LED Indicator : Turn Signal
(LH & RH), Head Lamp, High
Beam, Park, Transmission &
PTO Neutral, Battery Charging,
Low Engine Oil Pressure, Air
Filter Clog, High Temp., Low
Fuel Level, PTO 540, Heater
ON & ECS.
Lighting : Wedge type bulbs for
gauges illumination &
Halogen bulbs for Scuttle
lamp, Head lamps and Plow
lamp, Service, Brake.
CLUTCH
Type : Dry Dual Clutch
(Normally disengaged PTO clutch)
Diameter : 12" for Main Drive.
12" for P.T.O.
TRANSMISSION
Type : With Safety Neutral Switch
Speed section full Synchro
mesh, Range section full
Constantmesh, Shuttle
section Synchro mesh.
No. of gears : 12 - Forward, 12 - Reverse
STEERING : Hydrostatic
(Power Steering)
POWER TAKE OFF
Type :
Rear independent PTO shaft.
P.T.O. HP* (metric) : 70 max.
P.T.O. RPM : 540 (6 Splines) @ 2187 &
(Independent P.T.O.) 1000 (21 Splines) @ 2180
engine rpm with reversible shaft
BRAKES - OIL IMMERSED
Foot operated, independent with provision of interlock
for simultaneous operation. A hand brake lever is
provided for parking.
Number of lining : 5 each side
HYDRAULIC SYSTEM
Independent fully ‘live’ hydraulic pump.
Vary-Touch draft & position controls. Two spool auxiliary
valve as standard fitment.
Working pressure : 2690 PSI
Max. lifting force at
lower link hitch point : 5500 lbs.
Max. lifting force at
24" Behind hitch point : 3850 lbs.
Total Pump Flow : 22.3 Gallons/min.
at Rated Engine RPM
Hydraulic Pump Output : 17 Gallons/min.
at Rated Engine RPM
Steering Pump Output : 5.3 Gallons/min.
at Rated Engine RPM
3 Point linkage : Category II ball joints with
adjustable outside lateral
stabilizer.
Auxilliary valve : Standard - Double acting 2 sections
Optional - Double acting 1 section
Each section is detent type raise, lower and float position.
Hydraulic kickback in raise and lower.
