Driving
5.4 Off-road driving
5 - 50 3 302 709 en Operating manual
GMK5150L
12.01.2018
5.4.1 Transfer case – switching the off-road gear on/off
The off-road gear increases the thrust of the driven wheels.
Prerequisites
• Stop the truck crane.
• Select neutral on the transmission.
• Open the Driving (1) menu.
(A) – Switching on
• Select symbol (1) and confirm it – symbol (2)
is displayed, off-road gear engaged.
The speed is now limited to approx.
50 km/h (31 mph).
(B) – Switching off
• Select symbol (3) and confirm it – symbol (4)
is displayed, off-road gear is disengaged.
If neither the symbol (2) nor (4) is shown,
select a starting gear on the transmission and
shift back into neutral, or start up slowly.
If the error symbol is displayed, contact
Manitowoc Crane Care.
Neutral position
The transfer case is put into neutral position when the towing mode is
switched on;
à p. 8 - 31
