Crane operation
11.4 Operation of the rated capacity limiter
Operating manual 3 302 709 en 11 - 67
GMK5150L
12.01.2018
11.4.11 RCL override – version B
This section applies only when the supplied Lifting capacity tables contain an
entry other than
EN 13000 in the header (1), e. g. the entry ASME.
For standard
EN 13000; à RCL override – version A, p. 11 - 63.
H
The information in this section only applies when the Standard slewing
range type is activated. When the
MAXbase slewing range type is active, the
system automatically switches to RCL override Version A;
à p. 11 - 63.
RCL override
• Press the button (1) once – the information
message (2) is displayed.
– The crane movements are enabled.
– If you do not trigger a control lever move-
ment within 10 seconds after the override,
you must press the button (1) again.
– The speed of the movements which
increase the load moment is reduced
to 15%.
Cancelling the override
The override will be cancelled when you:
– press button (1) again, or
– do not activate the control lever for 10 seconds, or
switch off the ignition.
G
Risk of accidents due to overridden or faulty RCL
It is not permitted to work with an overridden or faulty RCL.
Set down the load immediately and stop operating the crane if the RCL is
faulty.
You may override the RCL only if it becomes absolutely necessary to do so
in the event of an emergency. This is to put the truck crane into a safe state
in the event of a malfunction. In this case, do not perform any movements
that would increase the load moment.
