08.02.2018
2 3 302 716 en Additional pages GMK
GMK5150/GMK5150L
Length specifications Percentages
Overall widths Individual widths
Control
unit
Lifting
capacity
table
7.600 m (24.9 ft) 3.800 m (12.5 ft) 100% 100%
6.700 m (22.0 ft) 3.350 m (11.0 ft) 83% 83%
5.900 m (19.4 ft) 2.950 m (9.7 ft) 61% 66%
5.100 m (16.7 ft) 2.550 m (8.4 ft) 51% 50%
2.500 m (8.2 ft) 1.250 m (4.1 ft) 0% 0%
GMK4100L-1
Length specifications Percentages
Overall widths Individual widths
Control
unit
Lifting
capacity
table
7.200 m (23.6 ft) 3.600 m (11.8 ft) 100% 100%
6.250 m (20.6 ft) 3.125 m (10.3 ft) 81% 80%
5.300 m (17.4 ft) 2.650 m (8.7 ft) 61% 60%
3.800 m (12.4 ft) 1.900 m (6.2 ft) 31% 40%
2.340 m (7.6 ft) 1.170 m (3.8 ft) 0% 0%
GMK3060
Length specifications Percentages
Overall widths Individual widths
Control
unit
Lifting
capacity
table
6.20 m (20.3 ft) 3.10 (10.2 ft) 100%
None4.40 m (14.4 ft) 2.20 (7.2 ft) 51%
2.32 m (7.6 ft) 1.16 (3.8 ft) 0%
