Matrix ETERNITY GE User Manual

96 Matrix ETERNITY Quick Start
ETERNITY ME TWT16
L1
1
2
3
4
RJ45-1
(Blue)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
TWT 01
TWT 02
TWT
TWT
04
Connector
Color
Connection H/w Port Offset
RJ45-2
(Orange)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
05
06
08
RJ45-3
(Green)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
09
10
12
RJ45-4
(Brown)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
13
14
16
TWT
TWT
TWT
TWT
TWT
TWT
TWT
TWT
TWT
TWT
TWT
TWT
