Matrix ETERNITY GE User Manual

90 Matrix ETERNITY Quick Start
ETERNITY ME SLT16 / ETERNITY ME ILC16
L1
1
2
3
4
RJ45-1
(Blue)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 01
SLT 02
SLT
SLT
04
Connector
Color
Connection H/w Port Offset
RJ45-2
(Orange)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 05
SLT 06
SLT
SLT
08
RJ45-3
(Green)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 09
SLT
10
SLT
SLT
12
RJ45-4
(Brown)
Blue - (Blue & White)
Orange - (Orange & White)
Green - (Green & White)
Brown - (Brown & White)
SLT 13
SLT
14
SLT
SLT
16

Matrix ETERNITY GE Specifications

General

Brand	Matrix
Model	ETERNITY GE
Category	PBX
Language	English
