Matrix ETERNITY GE User Manual

104 Matrix ETERNITY Quick Start
ETERNITY ME BRI4/BRI8
E&M03-SP(RxA), SP(RxB) Orange-Black
E&M03-04 CCS Green-Black
E&M04-M, SB Brown-Black
E&M04-E, SG Grey-Black
E&M04-SP(RxA), SP(RxB) Blue-Yellow
E&M04-SP(A), SP(B) Orange-Yellow
BRI04/BRI08 CARD
(Lower MDF Connector)
Port Port Port Color
BRI01 TxA, TxB Blue-White BRI05 TxA, TxB Blue-White
BRI01 RxA, RxB Orange-White BRI05 RxA, RxB Orange-White
BRI01 V-, V+ Green-White BRI05 V-, V+ Green-White
BRI02 TxA, TxB Brown-White BRI06 TxA, TxB Brown-White
BRI02 RxA, RxB Grey-White BRI06 RxA, RxB Grey-White
BRI02 V-, V+ Blue-Red BRI06 V-, V+ Blue-Red
BRI03 TxA, TxB Orange-Red BRI07 TxA, TxB Orange-Red
BRI03 RxA, RxB Green-Red BRI07 RxA, RxB Green-Red
BRI03 V-, V+ Brown-Red BRI07 V-, V+ Brown-Red
BRI04 TxA, TxB Grey-Red BRI08 TxA, TxB Grey-Red
BRI04 RxA, RxB Blue-Black BRI08 RxA, RxB Blue-Black
BRI04 V-, V+ Orange-Black BRI08 V-, V+ Orange-Black
