Matrix ETERNITY GE User Manual

Matrix ETERNITY Quick Start 13
Installing E&M Card
• Unpack the E&M card.
• The E&M Card supports E&M Interface Type IV and Type V connection.
• To select the Interface Type you require, change the position of the jumpers on
the E&M module. See the table below for jumper position to set Interface Type.
• Select the Speech Interface—2-wire speech or 4-wire speech—as required, by
changing the jumper position on the E&M module. See the table below for
jumper positions.
• Select a universal slot for the E&M card and insert the card in the slot and
secure it.
• Connect the cables supplied with the E&M card into the connectors on the E&M
Card.
• Connect the free end of the cable into the E&M Ports of the other PBX/Router/
Tie Line equipment with appropriate crossing of the wires.
• For connecting the wires, refer the pinout details for each E&M Card Type and
for each E&M Type and Speech Interface Type given in the “Appendix”.
Function Jumper Position
J1 J2
Type IV E&M Interface (default position) AB AB
Type V E&M Interface BC BC
Function Jumper Position
J3 J4
4-wire speech interface AB AB
2-wire speech interface (default position) BC BC
