apply the brakes fully, change direction sud-
denly or drive on poor road surfaces thereby
injuring yourself or others.
G
Risk of injury
When the load protection net is fitted, the
row of seats behind it must not be occupied.
Vehicle occupants on this seat could other-
wise make contact with the load protection
net and sustain injuries in the event of an
accident, even if seat belts are worn.
i There are two possibilities when installing
the load protection net in the position behind
the front seats:
I
at the lashing eyelets in the foremost seat
rail positions (optimum position)
or
I
at the sides, at the lashing eyelets on the B-
pillar.
If you wish to install the load protection net be-
hind the rear bench seat, you must first remove
the load compartment cover (
e page 226).
1 Retainer
2 Tensioning element
3 Strap
4 Hook for load protection net
5 Lashing eyelets
E To fit: clip the load protection net into
upper retainers
1 in such a way that
straps
3 face towards the rear of the
vehicle.
E Position the lashing eyelets on the seat
rail, in the nearest position possible be-
hind the seat anchorage (
e page 88).
E Tightly fasten straps 3 on the load
protection net.
E Clip hook 4 on straps 3 into lashing
eyelets
5.
E Fold tensioning element 2 up.
E Pull the loose ends of straps 3 down
in the direction of the arrow until the
straps are tight.
E Fold tensioning element 2 down to
achieve the final tension on the straps.
E Refit load compartment cover, if neces-
sary.
E After travelling a short distance, check
that the load protection net is taut.
E Retighten, if necessary.
E To remove: remove load compartment
cover, if necessary (
e page 226).
Operation
Transporting loads with the vehicle
223
