Mitsubishi AL2-14MR-D User Manual

α
2 Simple Application Controllers
Specifications 2
ENG-10
2.3 Output Specification
Table 2.5: Relay Output Specifications
Description Relay Specification
Switched Voltage 250V AC~ or less, 30V DC or less
Max. Resistive Load
AL2-14MR-* (O01 - O06)
8A/COM
AL2-24MR-* (O01 - O04)
AL2-24MR-* (O05 - O09) 2A/point (4A/COM)
AL2-4EYR (EO1-EO4) 2A/point
Contact Life Cycle /
Resistance Load
AL2-14MR-* (O01 - O06)
100,000 Cycles at 8 Amps / 240V AC~ or 24V DC
AL2-24MR-* (O01 - O04)
AL2-24MR-* (O05 - O09)
100,000 Cycles at 2 Amps / 240V AC~ or 24V DC
AL2-4EYR (EO1-EO4)
Minimum Load 50mW (10mA at 5V DC)
Max. Inductive Load
AL2-14MR-* (O01 - O06)
249 VA (1/3 hp) / 125V AC~,
373 VA (1/2 hp) / 250V AC~
AL2-24MR-* (O01 - O04)
AL2-24MR-* (O05 - O09)
93 VA(1/8hp)/125V AC~,
93 VA(1/8hp)/250V AC~
AL2-4EYR (EO1-EO4)
Response Time ≤ 10 ms
Operation Indication Liquid Crystal Display
Isolation Circuit By Relay
Table 2.6: Transistor Output Specifications (Source Type only) of AL2-4EYT
Description Transistor Specification
Switched Voltage 5 - 24V DC (+20%,-5%)
Max. Resistive Load 1A / point (8 - 24V DC), 0.1A / point (5 - 8V DC)
Minimum Load 1.0mA
Max. Inductive Load 1A / 24V DC (24 W)
Response Time On/Off, Off/On (approx) ≤ 1ms
Open Circuit Current Leakage ≤ 0.1mA / 24V DC
Operation Indication Liquid Crystal Display
Isolation Circuit Photocoupler
