Mitsubishi AL2-14MR-D User Manual

α
2 Simple Application Controllers
Diagnostics 11
ENG-58
11.7 Cannot Use an Operation Key
Check the movement of the operation keys according to the following procedures when the
α
2
series will not accept a key operation. If the steps outlined in instructions (1) - (5) below can be
performed, the keys are operating properly. Please check if the key(s) are used in the program.
1) Place the controller in the Stop mode. Consult a Mitsubishi Distributor when the Stop mode
cannot be entered.
Caution
Perform the forced stop operation only after thoroughly checking that it is safe to do so.
Damage to the machine or controller or a safety issue could arise if the forced ON/OFF is
performed inappropriately.
If proper precautions are not taken, damage to the equipment or machine failure may occur.
Forced Stop Operation
a) Turn the
α
2 series power supply off.
b) Turn the power ON again while pushing the “OK” and
“ESC” keys at same time.
The screen at right is displayed for 5 seconds.
The option to place the controller in Stop mode will be
available for approximately five seconds. Press the
“OK” key to enter the Stop Mode. If no key is pressed,
the controller will default back into the Run mode.
c) Push the “ESC” key.
The “Top Menu” shown at right is displayed.
2) Scroll through the Top Menu with “ ” key or “ ” key.
Consult a Mitsubishi distributor when you cannot scroll.
3) Move the cursor to “ClockSet” with “ ” key or “ ” key,
and push the “OK” key twice.
The “ClockSet” screen at right is displayed.
Consult a Mitsubishi distributor when it is not displayed.
4) Try to change the month/year data using the “ ” key, “ ” key, “+” key and “-” key.
Consult a Mitsubishi distributor when editing is not possible.
Run
Stop
TopMenu
Run
Se t up TS
ProgEdi t
Cl ckSet
mm/dd/yyyy
09/06/2001
13 : 55 Thu
o
