12-64 Simple inspection and service
3 Parking brake effectiveness
Stop the vehicle on a dry downgrade, set the park-
ing brake and check to see if the parking brake can
hold the vehicle. If an appropriate downgrade is not
available, drive the vehicle at 8 km/h (5 mph), then
apply the parking brake and make sure that it works
satisfactorily.
If parking brake performance is in any way abnor-
mal, vehicle operation could be dangerous. Contact
an authorized dealer.
<Manual transmission vehicles>
Before performing the following inspections, make
sure that warning lamp is not illuminated.
1 Clutch pedal play
1. Check that the engine is not running.
2. Check that the parking brake is firmly set.
3. Press the clutch pedal by hand. You may feel a
distinctive resistance twice. The pedal move-
ment from the point you feel the first resis-
tance to the point you feel the second resistance
is the clutch pedal play . If the clutch pedal
play is not within the specified range or there is
no free movement to the first resistance point,
have the vehicle inspected by an authorized
dealer.
Inspection intervals
Every 10,000 km
(6,000 miles)
WARNING
Perform brake tests in a safe place that
allows for good visibility all around. During
the tests, be attentive to surrounding traffic
conditions.
Clutch – check
Inspection intervals
Every 10,000 km
(6,000 miles)
Clutch pedal play
32 to 44 mm
(1.26 to 1.73 in.)
Z17679
FKFM.book Page 64 Wednesday, January 28, 2009 9:21 AM
