5-24 Switches and controls
1 Arrangement of switches
Lighting switch
Turn signal lamp switch
Passing signal/dimmer switch
Auto cruise cancel switch and set/
resume switch P. 5-29
Wiper and washer switch
Hazard warning lamp switch
Exhaust brake switch
2 Lighting switch
The lighting switch can be used with the starter
switch in any position.
Turning the knob at the end of the lever controls the
illumination of lamps as follows:
*: Illuminated by daytime running light system
CAUTION
Keeping the headlamps on for a long period
without the engine running can drain the bat-
tery, making the engine impossible to start.
NOTE:
Even when the vehicle is operated with the lighting
switch in the “OFF” or position, the daytime
running light system causes the low-beam head-
lamps to be lit. (The headlamps are dimmer than
when activated using the lighting switch.) The
indicator lamp is also lit. When the parking brake is
applied or the engine is stopped, the headlamps
and the indicator lamp go off.
Combination switch
Switch
position
Clearance/side marker
lamps, identification lamps,
parking lamps, rear combina-
tion lamps, license plate
lamp, and meter illumination
lamps
Head-
lamps
OFF Off On*
On On*
On On
Z17274
Z05251
Z17275
FKFM.book Page 24 Wednesday, January 28, 2009 9:21 AM
