13-11
1 Replacing fuses
1. To access the fuses, hook your fingers in the
recesses formed behind the panel and pull
the panel toward you to remove it.
When reinstalling the panel, align the lugs on
the panel with the cuts in the dashboard,
insert the pins (in 8 places) in the holes ,
and push the panel into position by hand.
2. To remove a blown fuse , use fuse puller
located in the fuse box . Pinch and pull fuse
with the fuse puller. The circuit protected by
each fuse and its amperage (A) are indicated on
the reverse side of the panel.
Z17493
Z17494
Z09117
FKFM.book Page 11 Wednesday, January 28, 2009 9:21 AM
