Display unit
Status lamp
Display
USB port
On/off button
THE STATUS LAMP
The status lamp indicates current operating status. It:
• lights up white during normal operation.
• lights yellow in emergency mode.
• lights red in the event of a deployed alarm.
• flashes white during active notice.
• is blue when VVM S320 is switched off.
If the status lamp is red, you receive information and sug-
gestions for suitable actions on the display.
TIP
You also receive this information via myUplink.
THE USB PORT
Above the display, there is a USB port that can be used e.g.
for updating the software. Log into myuplink.com and click
the "General" and then "Software" tab to download the latest
version of the software for your installation.
TIP
If you connect the product to the network, you
can update the software without using the USB
port. See section "myUplink".
THE ON/OFF BUTTON
The on/off button (SF1) has three functions:
• start
• switch off
• activate emergency mode
To start: press the on/off button once.
To switch off, restart or activate emergency mode: press
and hold the on/off button for 2 seconds. This brings up a
menu with various options.
For hard switch off: press and hold the on/off button for 5
seconds.
To activate emergency mode when VVM S320 is switched
off: press and hold the on/off button (SF1) for 5 seconds.
(Deactivate the emergency mode by pressing once.)
THE DISPLAY
Instructions, settings and operational information are shown
on the display.
NIBE VVM S320Chapter 8 | Control - Introduction34
Control - Introduction
