Nibe VVM S320 Installer Manual

Technical specifications
1 x 230 V3 x 230 V3 x 400 VVoltage
Electrical data
799kWAdditional power
230 V ~ 50 Hz230 V 3N ~ 50 Hz400 V 3N ~ 50 HzRated voltage
3227.516AMax operating current
323216AFuse
2 – 752 – 752 – 75WOutput, GP1
2 – 452 – 452 – 45WOutput, GP6
IPX1BEnclosure class
Equipment Compliant with IEC 61000-3-12
For Connection Design Purposes, Compliant with IEC 61000-3-3 technical requirements
WLAN
11dbm2.412 - 2.484 GHz max power
Wireless units
4dbm2.405 - 2.480 GHz max power
Heating medium circuit, hot water coil
low energyEnergy class, GP1
low energyEnergy class, GP6
0.3 (3)MPa
(bar)
Max system pressure heating medium
0.05 (0.5)MPa
(bar)
Min system pressure heating medium
0.25 (2.5)MPa
(bar)
Cut-off pressure, heating medium
70°CMax HM temp
Pipe connections
22mmHeating medium ext Ø
22mmHot water connection ext Ø
22mmCold water connection ext Ø
22mmHeat pump connections ext Ø
Hot water and heating section
--178litreVolume, hot water heater (Cu)
--7.5litreVolume coil (Cu)
--178litreVolume, hot water heater (E)
--4.7litreVolume coil (E)
176176176litreVolume, hot water heater (Rf)
7.77.77.7litreVolume coil (Rf)
206206206litreVolume, total indoor
262626litreVolume buffer vessel
1.0 (10)1.0 (10)1.0 (10)MPa
(bar)
Max. permitted pressure in hot water heater
0.01 (0.1)0.01 (0.1)0.01 (0.1)MPa
(bar)
Min. permitted pressure in hot water heater
0.9 (9)1.0 (10)0.9 (9)MPa
(bar)
Cut-off pressure in hot water heater
Hot water heating capacity (comfort mode Normal) According to EN16147
--240litreTap volume 40 °C (comfort mode Medium) – Cu
207207207litreTap volume 40 °C (comfort mode Medium) – E, Rf
Dimensions and weight
600mmWidth
615mmDepth
1,8001,8001,800mmHeight without base
1,830 – 1,8501,830 – 1,8501,830 – 1,850mmHeight with base
1,9101,9101,910mmRequired ceiling height
--141kgWeight Cu (excl. packaging and without water)
123123123kgWeight Rf (excl. packaging and without water)
--163kgWeight E (excl. packaging and without water)
Lead in brass componentsSubstances according to Directive (EG) no. 1907/2006, article 33
(Reach)
--069 195Part number Copper – NIBE VVM S320 CU 3x400V
--069 196Part number Stainless steel – NIBE VVM S320 R 3x400V
--069 206Part number Enamel – NIBE VVM S320 E 3x400V
--069 197Part number Enamel – NIBE VVM S320 E 3x400V DK
NIBE VVM S320Chapter 13 | Technical data66
