7368 ISAM ONT G-240W-J Product Guide Configure a G-240W-J indoor ONT
Issue: 01 3FE-48009-AAAA-TCZZA 117
1 Select Network > US Classifier from the top-level menu in the GPON Home Gateway
window, and select the Policy tab, as shown in Figure 44.
All classifier policies are displayed in the policy table in the window.
Figure 44 US Classifier Policy window
Table 36 describes the fields in the US Classifier Policy window.
Table 36 US Classifier Policy parameters
Field
Description
Tunnel Type
The tunnel type is set to GRE and cannot be modified.
Tunnel Interface
Choose a tunnel interface from the drop-down menu: No Tunnel, GRE
Tunnel, or LAN traffic.
VLAN ID
Enter a VLAN ID (0-4094).
VLAN Tag
This field is not configurable. The VLAN tag is set to 8100 (hexadecimal).
VLAN Priority
Enter a VLAN priority level (0 to 7). A lower number indicates a higher
priority.
IP TOS/DSCP
This field is not configurable. All tunnel packets are generated with a
default DSCP value (usually 0).
Drop
Select this checkbox to drop the packets
