Nokia 7368 ISAM ONT G-240W-J User Manual

7368 ISAM ONT G-240W-J Product Guide Configure a G-240W-J indoor ONT
1
Issue: 01 3FE-48009-AAAA-TCZZA 153
Procedure 49 Reboot ONT
Select Maintenance > Reboot Device from the top-level menu in the GPON Home
Gateway window, as shown in Figure 68.
Figure 68 Reboot window
Procedure 50 Restore factory defaults
Select Maintenance > Factory Default from the top-level menu in the GPON Home
Gateway window, as shown in Figure 69.
2
Click Reboot to reboot the ONT.
3
STOP. This procedure is complete.

Nokia 7368 ISAM ONT G-240W-J Specifications

General

Manufacturer	Nokia
PON interface	GPON
Downstream bandwidth	2.488 Gbps
Upstream bandwidth	1.244 Gbps
Voice ports	2 x FXS
USB	1 x USB 2.0
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Device Type	Optical Network Terminal (ONT)
Model	G-240W-J
Ethernet ports	4 x GE
Wi-Fi	802.11 b/g/n
Power Supply	12V DC
