Nokia 7368 ISAM ONT G-240W-J User Manual

7368 ISAM ONT G-240W-J Product Guide Configure a G-240W-J indoor ONT
Issue: 01 3FE-48009-AAAA-TCZZA 83
Table 21 WAN status IPv6 parameters
Field
Description
WAN connection list
Drop-down menu listing all WAN connections. The connection
shown is the connection for which WAN status will be shown.
Enable/Disable
Select this checkbox to enable the WAN connection
VLAN
VLAN ID
WAN Link Status
Whether the WAN link is up or down
PON Link Status
Whether the PON link is up or down
Tx Packets
Number of packets transmitted on the WAN connection
Rx Packets
Number of packets received on the WAN connection
Tx Dropped
Number of packets dropped on the transmit WAN connection
Rx Dropped
Number of packets dropped on the receive WAN connection
Err Packets
Number of errored packets on the WAN connection
Auto Configure
IPv6 address
IPv6 address that identifies the device and its location
IPv6 Prefix
IPv6 prefix
IPv6 Gateway
IPv6 gateway address
Netmask
Network mask
Gateway
Gateway address
Primary DNS
Primary Domain Name Server
Second DNS
Secondary Domain Name Server
Procedure 11 Home networking information retrieval
1 Select Status > Home Networking from the top-level menu in the GPON Home Gateway
window, as shown in Figure 23.
2
Click Refresh to update the displayed information.
3
STOP. This procedure is complete.

Nokia 7368 ISAM ONT G-240W-J Specifications

General

Manufacturer	Nokia
PON interface	GPON
Downstream bandwidth	2.488 Gbps
Upstream bandwidth	1.244 Gbps
Voice ports	2 x FXS
USB	1 x USB 2.0
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Device Type	Optical Network Terminal (ONT)
Model	G-240W-J
Ethernet ports	4 x GE
Wi-Fi	802.11 b/g/n
Power Supply	12V DC
