Nokia 7368 ISAM ONT G-240W-J User Manual

Configure a G-240W-J indoor ONT 7368 ISAM ONT G-240W-J Product Guide
86 3FE-48009-AAAA-TCZZA Issue: 01
Table 23 Optics module status parameters
Field
Description
Laser Bias Current (ONT ANI-ONT-Side Optical
Measurements)
Laser bias current, measured in uA
Optics Module Voltage (ONT ANI-ONT-Side Optical
Measurements)
Optics module voltage, measured in V
Optics Module Temperature (ONT ANI-ONT-Side Optical
Measurements)
Optics module temperature, measured in C
Rx Optics Signal Level at 1490 nm (ONT ANI-ONT-Side
Optical Measurements)
Received optics signal level at 1490 nm,
measured in dBm
Tx Optics Signal Level at 1310 nm (ONT ANI-ONT-Side
Optical Measurements)
Transmitted optics signal level at 1310 nm,
measured in dBm
Lower (ONT ANI-ONT-Side Optical Measurements-Optical
Threshold)
Lower optical threshold, measured in dBm
Upper (ONT ANI-ONT-Side Optical Measurements-Optical
Threshold)
Upper optical threshold, measured in dBm
Procedure 13 Statistics retrieval
1 Select Status > Statistics from the top-level menu in the GPON Home Gateway window.
Statistics are available for LAN ports, WAN ports, and WLAN ports.
Figure 25 shows the statistics for the LAN ports.
2
Click Refresh to update the displayed information.
3
STOP. This procedure is complete.
