Nordson DuraBlue D4L Customer Product Manual

Parts
7-17
Part 1032059B
E 2003 Nordson Corporation
Manual 41-DURABLUE-MA-02
Hose Support Kit
Part Description Quantity
1030539
Kit, support, hose, double
—
- - - - - -
S Bracket, support, hose, single
2
- - - - - -
S Nut, hex, M5, Nylok
2
- - - - - -
S Washer, flat, oversized, 5
2
- - - - - -
S Cuff, cap, hose, corrugated
2
- - - - - -
S Tube, Nylon, corrugated, split
2
- - - - - -
S Screw, pan-head, M4 x10
4
- - - - - -
S Cuff, hose, corrugated
2
- - - - - -
S Bracket, slide, support, 1-hose
2
- - - - - -
S Plate, hose support
1
- - - - - -
S Washer, flat, M6
2
Pressure Gage Kit
Part Description Quantity
1030537
Kit, gage, 1500 psi
—
- - - - - -
S Gage, 1500 psi, with chemical seal
1
- - - - - -
S Tape, roll
1
- - - - - -
S Swivel, 37,
9
/
16
–18 x
1
/
4
1
- - - - - -
S Connector with O-ring, hose,
9
/
16
–18
1
Handgun Support Kit
Part Description Quantity
1030530
Kit, handgun support
—
- - - - - -
S Bracket, handgun support
1
- - - - - -
S Screw, hex, M5 x 30
2
- - - - - -
S Washer, flat, oversized, M5
2
- - - - - -
S Nut, hex, M5, Nylok
2
Automatic Pressure Control
Part Description Quantity
1028627
Assembly, tachometer, generator and cable
1
1032537
Controller, FC1, DuraBlue
1
1024689
Valve, run-up PCV, 1100 psi
1
1030537
Kit, gage, 1500 psi
1
