Serial Communications Settings Section 5-2
122
12. Exit Serial Communications settings window
Repeat the procedures 5 to 9 as required. Press the [OK] button when
completed.
13. System setup for serial communications
When an actual PLC performs serial communications, it is necessary to
set communications parameters to the PLC’s I/O memory areas. Also for
the CX-Simulator, use the CX-Programmer to set Serial Communications
mode, Start bits, Data length, Stop bits, Parity, Baud rate, etc. according
to the manuals for each Serial Communications Unit.
Note DIP switch setting for “RS-232C port communications parameters” (pin 5) is
fixed to “Use parameters set in the PLC Setup” (OFF).
For CPU Unit’s RS-232C port (Port 2) settings, refer to 7-1-2 PC Setup in
CS/CJ Series Operation Manual, and for Serial Communications Board/Unit
settings, refer to 4-2 Setup Area Allocations in CS/CJ Series Serial Communi-
cations Boards/Unit Operation Manual.
Note When using the RS-232C port (Port 2) on the CPU Unit, if a protocol not sup-
ported by the CX-Simulator is set in PLC Setup, communications can not be
performed.
