[ SYSTEM MENU ]
Quit
Transmit Mode
Maintenance Mode
[ MAINTENANCE MENU ]
Quit
PT Setting
I/O Check
DIP-SW Status
Init. Memory
Memory Switch
Comm. Type
Key Sound
Buzzer Sound
Host Link
OFF
Bk light Off
Tool Mode
OFF
None
NT20M
(1/2)
Quit
WRT&
EXIT
MEMORY SW MENU
Page
96
Various System Settings
Section 3-8
Set the support tool mode by the menu operation from the system menu shown
below.
Select “Maintenance Mode”.
Select “Memory Switch”.
Each time the “Tool Mode” touch
switch is pressed, the setting
option alternates between
“NT20S” and “NT20M”.
(The figure to the left shows the
NT20S-ST121-EV3 screen.)
To quit after setting the selected item, press the WRT & EXIT touch switch. To quit
without setting, press the Quit touch switch. The NT20S will enter the RUN mode.
S When “NT20M” is set, the NT20M compatible mode is established and the termi-
nal can be used as an NT20M.
S When “NT20S” is set, the terminal can be used as an NT20S.
