243
Specifications
Appendix A
APPENDIX A
Specifications
General Specifications
Item Specification
Power supply voltage 24 VDC
Allowable power supply voltage range 20.4 VDC to 26.4 VDC (24 VDC –15% +10%)
Power consumption 10 W max.
Inrush current 3 A max.
Ambient operating temperature 0 to +50_C (with no freezing)
Storage temperature –20 to +70_C
Ambient operating humidity 35 to 85% RH (with no condensation)
Operating environment No corrosive gases.
Resistance to electrostatic discharge Level 3 (IEC801-2)
In air "8 kV, contact "6 kV, indirect "7 kV
Electromagnetic field strength 10 V/m (IEC801-3)
Fast transient/burst noise Power supply line: 2 kV (IEC801-4)
I/O line: 0.25 kV
Damped oscillatory wave Power supply line: 1 kV (IEC255-4)
Vibration resistance 10 to 22 Hz with 1.5 mm double amplitude for a total of 30 min. in X, Y, and Z
directions.
22 to 500 Hz with 1.5 G {14.7 m/s
2
} acceleration in X, Y, and Z directions.
Shock resistance Durability: 30 G, 3 times each in X, Y, and Z directions.
Malfunction: 20 G, 3 times each in X, Y, and Z directions.
Dimensions (mm) 190 (W) x 110 (H) x 58 (D) mm
Weight 0.7 kg max.
Enclosure ratings Front panel:
Equivalent to IP65 (front face waterproof construction).
Rear case: IP20
Terminals: IP00
Applicable standards IEC1131-2 (1992)
EN50081-2 (1992)
