3-1 Servo Drive Specifications
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
3
Specifications
Main Circuit and Motor Connections
When wiring the main circuit, use proper wire sizes, grounding systems, and noise resistance.
R88D-KTA5L/-KT01L/-KT02L/-KT04L
R88D-KT01H/KT02H/-KT04H/-KT08H/-KT10H/-KT15H
Main Circuit Connector Specifications (CNA)
Motor Connector Specifications (CNB)
Precautions for Correct Use
Tighten the ground screws to the torque of 0.7 to 0.8 N•m (M4) or 1.4 to 1.6 N•m (M5).
Symbol Name Function
L1 Main circuit power
supply input
R88D-KT@L
(50 to 400 W) : Single-phase 100 to 120 VAC (85 to 132 V) 50/60 Hz
R88D-KT@H
(100 W to 1.5 kW) : Single-phase: 200 to 240 VAC (170 to 264 V) 50/
60 Hz
(100 W to 1.5 kW) : 3-phase: 200 to 240 VAC (170 to 264 V) 50/60 Hz
Note. Single-phase should connect to L1 and L3.
L2
L3
L1C Control circuit power
supply input
R88D-KT@L : Single-phase 100 to 120 VAC (85 to 132 V) 50/60 Hz
R88D-KT@H : Single-phase 200 to 240 VAC (170 to 264 V) 50/60 Hz
L2C
Symbol Name Function
B1
External
Regeneration
Resistor connection
terminals
R88D-KTA5L/-KT01L/-KT02L/-KT01H/-KT02H/-KT04H:
Normally, do not short B1 and B2. Doing so may cause malfunctions.
If there is high regenerative energy, connect an External
Regeneration Resistor between B1 and B2.
R88D-KT04L/-KT08H/-KT10H/-KT15H:
Normally B2 and B3 are shorted. Do not short B1 and B2. Doing so
may cause malfunctions. If there is high regenerative energy, remove
the short-circuit bar between B2 and B3 and connect an External
Regeneration Resistor between B1 and B2.
B3
B2
U Motor connection
terminals
Phase U These are the output terminals to the Servomotor.
Be sure to wire them correctly.
V Phase V
W Phase W
