2-25
2-4 External and Mounting Dimensions
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
2-4 External and Mounting Dimensions
Servo Drive Dimensions
Single-phase 100 VAC: R88D-KTA5L/-KT01L (50 to 100 W)
Single-phase/3-phase 200 VAC: R88D-KT01H/-KT02H (100 to 200 W)
Wall Mounting
External dimensions Mounting dimensions
13070
40
150
40
28
6
150
140
2-M4
