2-11
2-3 Standard Model Tables
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
2
Standard Models and External Dimensions
Servo Drive and Servomotor Combination Tables
The tables in this section show the possible combinations of OMNUC G5-series Servo Drives
and Servomotors. The Servomotors and Servo Drives can only be used in the listed
combinations.
“-@” at the end of the motor model number is for options, such as the shaft type, brake, oil seal
and key.
3,000-r/min Servomotors and Servo Drives
* Use these combination with caution because the Servo Drive and Servomotor have different
capacities.
Voltage
Servomotor
Servo Drive
Rated
output
With incremental
encoder
With absolute
encoder
Single-phase
100 V
50 W R88M-K05030H-@ R88M-K05030T-@ R88D-KTA5L
100 W R88M-K10030L-@ R88M-K10030S-@ R88D-KT01L
Single-phase/
3-phase 100 V
200 W R88M-K20030L-@ R88M-K20030S-@ R88D-KT02L
400 W R88M-K40030L-@ R88M-K40030S-@ R88D-KT04L
Single-phase/
3-phase 200 V
50 W* R88M-K05030H-@ R88M-K05030T-@ R88D-KT01H
100 W R88M-K10030H-@ R88M-K10030T-@ R88D-KT01H
200 W R88M-K20030H-@ R88M-K20030T-@ R88D-KT02H
400 W R88M-K40030H-@ R88M-K40030T-@ R88D-KT04H
750 W R88M-K75030H-@ R88M-K75030T-@ R88D-KT08H
1 kW* R88M-K1K030H-@ R88M-K1K030T-@ R88D-KT15H
1.5 kW R88M-K1K530H-@ R88M-K1K530T-@ R88D-KT15H
3-phase 200 V
2 kW R88M-K2K030H-@ R88M-K2K030T-@ R88D-KT20H
3 kW R88M-K3K030H-@ R88M-K3K030T-@ R88D-KT30H
4 kW* R88M-K4K030H-@ R88M-K4K030T-@ R88D-KT50H
5 kW R88M-K5K030H-@ R88M-K5K030T-@ R88D-KT50H
3-phase 400 V
750 W* R88M-K75030F-@ R88M-K75030C-@ R88D-KT10F
1 kW* R88M-K1K030F-@ R88M-K1K030C-@ R88D-KT15F
1.5 kW R88M-K1K530F-@ R88M-K1K530C-@ R88D-KT15F
2 kW R88M-K2K030F-@ R88M-K2K0
30C-@ R88D-KT20F
3 kW R8
8M-K3K030F-@ R88M-K3K030C-@ R88D-KT30F
4 kW* R88M-K4K030F-@ R88M-K4K030C-@ R88D-KT50F
5 kW R88M-K5K030F-@ R88M-K5K030C-@ R88D-KT50F
To Next Page
