3-6 External Regeneration Resistor Specifications
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
3
Specifications
3-6 External Regeneration Resistor
Specifications
External Regeneration Resistor Specifications
R88A-RR08050S
R88A-RR080100S
R88A-RR22047S1
Model
Resistance
value
Nominal
capacity
Regeneration
absorption for 120
° C
temperature rise
Heat
radiation
condition
Thermal switch
output specifications
R88A-
RR08050S
50 Ω 80 W 20 W
Aluminum
350 × 350,
Thickness: 3.0
Operating temperature:
150°C ± 5%
NC contact
Rated output (resistive
load): 125 VAC, 0.1 A max.
30 VDC, 0.1 A max.
(minimum current: 1 mA)
Model
Resistance
value
Nominal
capacity
Regeneration
absorption for 120 ° C
temperature rise
Heat
radiation
condition
Thermal switch
output specifications
R88A-
RR080100S
100 Ω 80 W 20 W
Aluminum
350 × 350,
Thickness: 3.0
Operating temperature:
150°C ± 5%
NC contact
Rated output (resistive
load): 125 VAC, 0.1 A max.
30 VDC, 0.1 A max.
(minimum current: 1 mA)
Model
Resistance
value
Nominal
capacity
Regeneration
absorption for 120
° C
temperature rise
Heat
radiation
condition
Thermal switch
output specifications
R88A-
RR22047S1
47 Ω 220 W 70 W
Aluminum
350 × 350,
Thickness: 3.0
Operating temperature:
150°C ± 5%
NC contact
Rated output (resistive
load): 250 VAC, 0.2 A max.
42 VDC, 0.2 A max.
(minimum current: 1 mA)
