6-50
6-15 Hybrid Vibration Suppression Function
OMNUC G5-SERIES AC SERVOMOTOR AND SERVO DRIVE USER'S MANUAL
6
Applied Functions
6-15
Hybrid Vibration Suppression Function
Outline of Operation
This function suppresses the vibration that is caused by the amount of the torsion between the
motor and the load in the Fully-closed Control Mode. You can use this function to raise the gain
setting.
The hybrid vibration suppression function can be used in the following situations.
Fully-closed Control Mode
When Servo is ON
When there is no trouble with the motor's normal rotation
Parameters Requiring Settings
Operating Procedure
1. Set the Hybrid Vibration Suppression Gain (Pn634) to the same value as the position
loop gain.
2. Gradually increase the set value of the Hybrid Vibration Suppression Filter (Pn635)
while driving with fully-closed control and check the changes in the response.
If the response improves, find the combination of Pn634 and Pn635 that result in the optimal
response by adjusting them.
Precautions for Correct Use
This function is effective when the amount of torsion between the motor shaft and the load is large.
It may be less effective when the amount of torsion is small.
Parameter
number
Parameter name Explanation Reference
Pn634
Hybrid Vibration
Suppression Gain
Set the hybrid vibration suppression gain.
In general, set it to the same value as the position
loop gain, and finely adjust it based on the
situation.
P.8-66
Pn635
Hybrid Vibration
Suppression Filter
Set the hybrid vibration suppression filter.
P.8-66
